Welding Helmet
Welding Helmet Tecxtra M800H Auto Darkening
Main Characteristics:
- The Auto Darkening welding Helmet M800H protects eyes and face from sparks, splashes and harmful radiation. The helmet offers multiple option and high wearing comfort due to its large viewing area.
- Liquid crystal of high quality and optical coating shields from ultraviolet and infrared rays (level of protection: 16) are adopted to protect the welding operator from being injured by harmful rays such as ultraviolet rays, infrared rays, etc.
- The automatic technology used in controlling circuit makes it possible for the mask to react to the arc in 3/10000 second and change strong light to dark light. As a result, it can protect eyes from being injured by sudden arc.
- Dark shade, stepless control, set by hand according to actual situation.
- Dark to light: 0.1 s - 0.8 s, stepless control.
- The products the is in full conformity with ANSI ISEA Z87:1-2015 standards.
Main technical parameter:
Filter model
M800H
Filter size
Filter size 133 mm × 114 mm × 10 mm / 5.2“ x 4.5“ x 0.4“
Active viewing area
100 mm x 93 mm / 3.9“ x 3.7“
Light shade
DIN 4
Darkening shades
DIN 5–9/ DIN 9–13
Way to shift dark state
Stepless shift
Switching time
3/10000s
Sensitivity adjustment
The external control
Delay time
0.1 - 0.8 S
Power supply
Lithium battery & solar supply
Battery type
CR2450 (600 mAh)
Operating temperature
-5 °C - +55 °C / 23 °F - 131 °F
Storage temperature
-5 °C - +55 °C / 23 °F - 131 °F
Sensors to weld arc
4
Protect grade against UVB
DIN16
Grind
YES
Low battery (LED)
YES
